High-Performance 2 Channel Power Amplifier For Audio System Integration CD8000

Products

Public Address System Amplifier

High-Performance 2 Channel Power Amplifier For Audio System Integration CD8000

MOQ:	30pcs
Price:	Negotiable
Standard Packaging:	size：430mm132mm487mm in carton
Delivery Period:	30-60days After Deposit
Payment Method:	T/T, Western Union, MoneyGram
Supply Capacity:	300pcs one month

Detail Information

Product Description

Detail Information

Place of Origin

china

Brand Name

P-AMF

Certification

CE,ISO

Model Number

CD8000

Damp Modulus 8Ω:

Input Voltage:

180V-240V

Protection:

Short Circuited/DC/Overload/Turnon Delay/High Temperature(Optional)

Brand Customization:

OEM/ODM

Packing Details:

Cartons And Plastic Bags

Input Impedance:

47k Ohms

Total Harmonic Distortion:

Less Than 0.1%

Highlight:

High Performance 2 Channel Power Amplifier

CD8000 2 Channel Power Amplifier

Product Description

High-Performance 2 Channel Power Amplifier for Audio System Integration CD8000

Operational Principles

Amplification Process:
- The amplifier takes a low-level audio signal (like from a mixer) and uses transistors or tubes in the amplification stage to increase the signal's power. This process involves manipulating the input signal to produce a stronger output without altering the original sound characteristics.
Feedback Mechanism:
- Many amplifiers use negative feedback to improve linearity and reduce distortion. By feeding a portion of the output back to the input, the amplifier can adjust its output to match the input more closely.
Thermal Management:
- Heat generated during operation is a critical factor. Effective thermal management through heatsinks or fans ensures that the amplifier operates within safe temperature limits, thereby prolonging its lifespan and maintaining performance.

Advantage Of Factory

Our company was established in 1998, specializing in the development, production, and sales of audio electronic products for over 20 years. Complete equipment, advanced production technology, multiple high-efficiency assembly lines, semi-automatic production, ensuring quality and quantity. With strong technology and advanced management experience, perfect after-sales service (for example: after-sales troubleshooting, maintenance consulting, spare parts replacement, etc.) based on the forefront of the audio industry, dedicated to new and old customers for a better tomorrow.

Specifications
Load Impedance	4Ω	8Ω
Stereo Output	2 X 900W	2 X 600W
Bridge Output Power	2800W	1500W

Input Impedance	20K OHMS
Frequency Response	10Hz-20KHz +/-1dB
Total Harmonic Distortion	＜0.02%
Slew Rate	40V/μS
Signal Noise Ratio	＞105dB
Damp Modulus 8Ω	＞250
Output Category	ClassH
Cooling	Two Cooling Fans
Input Sensitivity	0.75V
Input Voltage	180V-240V
Protection	Short circuited/DC/Overload/Turnon delay/High temperature(Optional)
Dimensions (W x H x D), mm	430mm132mm487mm
Gross Weigh	28KG
Packing Dimensions	0.08m³

Tags:

Products

MOQ:	30pcs
Price:	Negotiable
Standard Packaging:	size：430mm132mm487mm in carton
Delivery Period:	30-60days After Deposit
Payment Method:	T/T, Western Union, MoneyGram
Supply Capacity:	300pcs one month

Detail Information

Product Description

Detail Information

Place of Origin

china

Brand Name

P-AMF

Certification

CE,ISO

Model Number

CD8000

Damp Modulus 8Ω:

＞250

Input Voltage:

180V-240V

Protection:

Short Circuited/DC/Overload/Turnon Delay/High Temperature(Optional)

Brand Customization:

OEM/ODM

Packing Details:

Cartons And Plastic Bags

Input Impedance:

47k Ohms

Total Harmonic Distortion:

Less Than 0.1%

Minimum Order Quantity:

30pcs

Price:

Negotiable

Packaging Details:

size：430mm*132mm*487mm in carton

Delivery Time:

30-60days After Deposit

Payment Terms:

T/T, Western Union, MoneyGram

Supply Ability:

300pcs one month

Highlight

High Performance 2 Channel Power Amplifier

CD8000 2 Channel Power Amplifier

Product Description

High-Performance 2 Channel Power Amplifier for Audio System Integration CD8000

Operational Principles

Amplification Process:
- The amplifier takes a low-level audio signal (like from a mixer) and uses transistors or tubes in the amplification stage to increase the signal's power. This process involves manipulating the input signal to produce a stronger output without altering the original sound characteristics.
Feedback Mechanism:
- Many amplifiers use negative feedback to improve linearity and reduce distortion. By feeding a portion of the output back to the input, the amplifier can adjust its output to match the input more closely.
Thermal Management:
- Heat generated during operation is a critical factor. Effective thermal management through heatsinks or fans ensures that the amplifier operates within safe temperature limits, thereby prolonging its lifespan and maintaining performance.

Advantage Of Factory

Specifications
Load Impedance	4Ω	8Ω
Stereo Output	2 X 900W	2 X 600W
Bridge Output Power	2800W	1500W

Input Impedance	20K OHMS
Frequency Response	10Hz-20KHz +/-1dB
Total Harmonic Distortion	＜0.02%
Slew Rate	40V/μS
Signal Noise Ratio	＞105dB
Damp Modulus 8Ω	＞250
Output Category	ClassH
Cooling	Two Cooling Fans
Input Sensitivity	0.75V
Input Voltage	180V-240V
Protection	Short circuited/DC/Overload/Turnon delay/High temperature(Optional)
Dimensions (W x H x D), mm	430mm132mm487mm
Gross Weigh	28KG
Packing Dimensions	0.08m³
